Industrial & Warehouse
PowerSwap Nucleus Classic
Seamless AC power that swaps like a spare tire — pull a discharged battery, drop in a charged one, and keep working through a 24/7 shift.
Up to 920 Wh
240W continuous
11 lb battery pack
or call (800) 222-1440
On the Cart
Built into the base of a fully loaded workstation.
Here the PowerDock Dual Station sits low in the cart’s base, under a monitor, laptop, keyboard tray, handheld scanner, and a mounted label printer — the kind of equipment stack the 240W-continuous, two-battery configuration is sized for. Swap a depleted pack for a charged one in seconds without powering anything down.
Runs equally well as a stand-alone unit off the cart, or integrated into an NB, PC, or Apex Series workstation like the one shown here.
What’s Built In
Every feature that makes this our most popular swappable system.
- Lithium Iron Phosphate cells — the most thermally stable lithium chemistry available
- 5–7 year battery life or 3,000 charge cycles
- Seamless AC output — no DC-specific hardware to source
- Remote battery monitor, readable up to 50 ft away
- Integrates with NB, PC & Apex Series workstations, or runs stand-alone
- Also available as a compact Nucleus Mini configuration
Weight & Dimensions
Light enough to swap one-handed, sized to fit most carts.
Each swappable battery weighs about as much as a bag of groceries — no lift-assist or two-person carry required. The PowerDock station it snaps into mounts to the cart frame and holds one or two batteries for the full 920 Wh, 240W configuration.
Battery Pack (PSNU3.6)
Weight
11 lbs
Dimensions (W × L × H)
6.5″ × 12.82″ × 6.4″
PowerDock Dual Station
Weight
15 lbs
Dimensions (W × L × H)
17.75″ × 11.63″ × 10″
The compact Nucleus Mini battery weighs about 6 lbs, for lighter-duty applications.
Full Specifications
Every number, for the people who ask for them.
| Model | PowerDock Dual (PWD2C), 2-Battery Configuration |
| Battery Weight | 11 lbs (5 kg) each |
| Battery Dimensions | 6.5″ W × 12.82″ L × 6.4″ H |
| Dock Dimensions / Weight | 17.75″ × 11.63″ × 10″ / 15 lbs (6.8 kg) |
| Battery Chemistry | Lithium Iron Phosphate |
| Continuous / Surge Power | 240W / 825W (2-battery) |
| Battery Bank | 920 Wh (2-battery) / 460 Wh (1-battery) |
| Charge Time | 4–5 hrs |
| Operating Temp. Range | 50–104°F |
Ready to spec the Nucleus Classic?
Tell us your shift pattern and equipment list, and we’ll size the right battery count.
